PHF Series High Flow Pleated Filter Cartridge has 6.7inch large diameter, single open-ended with an outside to inside flow pattern. It offers a high flow rate solution with quick changes to the cartridge filters for advanced water filtration systems including industrial and commercial osmosis type water or sea water filtration. It provides a cost effective alternative to 2.5inch OD style filter cartridges in high flow applications.
SHF Series High Flow Pleated Filter Cartridge provides a cost effective alternative to 2-1/2''inch OD style filter cartridges in high flow applications. The filter can handle flow rates up to 800lpm, significantly reducing the number of cartridges required and the housing size. Water treatment volume per Super-High Flowment filter cartridge equals to 10×40'' length, 2-1/2''diameter cartridges.
With horizontal pleat structure, MHFB Series High Flow Pleated Filter Cartridge is highly efficiency, outside to inside flow direction liquid filtration. It's designed for applications with high contaminant removal requirement. The filter has a big diameter of 6.5inch/165mm, horizontal pleated depth media cartridge design permits higher flow rates than standard 2.5''diameter filter cartridges resulting in significantly fewer required filter cartridges for a given flow.
MHF Series High Flow Pleated Filter Cartridge is made from depth fine PP non-woven fabrics. It has a big diameter of 6.5inch/165mm, pleated cartridge is with an outside to inside flow pattern and a core construction. The long service life and high flow rate result in low investment and less manpower in many applications.
HF Series High Flow Pleated Filter Cartridge is made from depth fine PP non-woven fabrics. The filter has a big diameter of 6inch/152mm, single open ended, pleated cartridge with an inside to outside flow pattern and a core-free construction. With a high flow rate, easy installation and quick changout, it is widely used for different application.
The large 6inch(152mm) diameter BC series filter cartridge easily retrofits into existing size 1 and size 2 bag housing. It combines the performance advantages of cartridge filters with the easy use of bag filter systems.Filtration customers no longer have to choose between cartridge and bag technologies. This filter cartridge delivers lower operating costs than conventional cartridges for critical applications. The high surface area resulting long service life translates into fewer cartridge change outs and lower disposal cost. And the large diameter configuration is more economical than the equivalent number of standard 10'' filters, thus delivering additional savings on filter purchases.
